CEMENT PRODUCTS - Technical Data Sheet

Although water is needed in the hydration reaction of cement (q.v.), excess water added for workability of the concrete and mortar creates voids that decrease strength and increase water permeability. Plasticizers are used in cements to cut water demand by 2-4% and decrease void volume. More recently, dispersant so-called superplaticizers have been formulated being consumed which can reduce water demand by about 15-20% and more as per the application. This results in much higher early strength and less water permeability in the concrete. Super plasticizers function by absorbing on the surface of alite moles of Tricalcium Silicate, principal constituent of Portland cement. This absorption increased the charge repulsion of the particles allowing less water to be used while maintaining low slurry viscosity i.e. (increased workability). Reportedly, super plasticizers retard the hydration of alite by limiting its interaction with water molecules and minimizing the dissolution of calcium ions that normally further react as the cement cures.

The two main classes of super plasticizers are Melamine-Formaldehyde condensates & Naphthalene Sulfonate condensates. Newer Superplaticizer “DISPERSWELL-CM” derived from Neutralize Carboxylic Acid based polymer requires lower dosage for earlier type available product. “DISPERSWELL-CM” is an aqueous solution of chemical dispersants with remarkable dispersing and fluidifying action giving optimum dispersion of the cement particles. The dispersing action produces a dramatic increase in workability, suicient to achieve a free -flowing properties, improves water tightness reduces shrinkage; increase compressive strength due to reduced water cement ratio.

Product Specification

In General Please Note the Dosage for Two Layer Pavers Blocks

TOP LAYER : [ Pigmented in dierent shades ] 400 gsms / one bag of cement
BOTTOM LAYER :[ UnPigmented 50-60 mm Layer ] 400 gsms / one bag of cement
The dosage can be adjusted as per the desired required quality at your end

[A] PROCEDURE FOR DOSAGE RECOMENDATION

Water 200 gms Water 180 gms. Cement 050 gms Dis-CM 020 gms. Cement 050 gms.
In glass beaker weight Water and Cement – Settles immediately In glass beaker weight Water, Dis-CM and Cement—Do not Settle


OR

PROCEDURE FOR DOSAGE RECOMENDATION

Sr.No.	Water	Dis-CM	Pigment	Viscosity in B4 Cup
Blank	1000 gms	-----	1000 gms	Observe viscosity
0.5% Dosage	1000 gms	5 gms	1000 gms	Observe viscosity
1.0% Dosage	1000 gms	10 gms	1000 gms	Observe viscosity

Note: The Water and Product should be Premixed before Additions of Fillers/Pigments

Regular Pavers Blocks / Concrete Products

400 ML / one bag of cement

Here the product DIS-CM, do not permit the water dehydration during production and hence retain water helps to achieve early strength without sprinkle of additional water for curing.

Packing / Storage

Packaging	Storage
12 months when stored in tightly sealed containers below 35.C	Material should be stored in an enclosed area and away from direct sunlight and heat.

DIBHALITE- FXWC is Epoxy based Solvent Free Two Component Systems, especially formulated for best performance of Adhesion to Road Studs both on Bitumen and Concrete Surfaces.

Moreover, it’s designed as resistance to UV rays, Water resistance and being inherent flexible properties also resist Expansion and Contraction due to heavy traffic movements along with weather changes during the year.

Moreover, being loaded with specific fillers can also be consumed for Concrete joints in RCC.

Product Specification

Surface Preparation

For better adhesion, it is essential to clean the surface on which the material is to be consumed. To remove dust, dirt or loose particles by emery paper, wire brush or blower. To get optimum performance the surface must be dry, free from oil grease. For concrete surface, old concrete surface should be examined for structural soundness. Unsound areas must be repaired and should be cured for required time.

Precaution

Mix only the required quantity of material, which can be utilized within stipulated pot- life to avoid solidification. Wash all the tools and tackles with industrial solvent immediately after the application is completed.

Self - Life / Storage
